Product Description:
The PCD/PCBN Grinding Machine is a cutting-edge tool designed for precision grinding of PCD (polycrystalline diamond) and PCBN (polycrystalline cubic boron nitride) tools. With a powerful spindle power of 2.2kw, this machine is engineered to deliver high-performance results for a wide range of applications.
Equipped with an advanced image system resolution of 1280dpi*960dpi, the PCD/PCBN Grinding Machine ensures superior accuracy and detail in the grinding process. This high-resolution imaging system enables operators to achieve precise and consistent results with every use.
The readout of linear gratings on this PCD grinder is an impressive 0.001mm, allowing for ultra-precise measurements and adjustments during the grinding process. This level of precision ensures that even the most intricate PCD and PCBN tools can be sharpened to perfection with ease.
One of the standout features of the PCD/PCBN Grinding Machine is its grinding wheel height adjustment capability, which offers a generous range of 140mm. This versatile height adjustment feature allows operators to customize the grinding process to suit their specific needs, resulting in optimal grinding performance and efficiency.
Whether you are working with PCD or PCBN tools, the PCD/PCBN Grinding Machine is a reliable and efficient solution for all your grinding needs. With its powerful spindle power, high-resolution image system, precise linear gratings readout, and flexible grinding wheel height adjustment, this machine is designed to deliver exceptional results and exceed expectations.
Invest in the PCD/PCBN Grinding Machine today and experience the cutting-edge technology and precision engineering that make it a standout choice for PCD and PCBN tool grinding applications.
Applications:
CTSTC PCD Grinding Machine is a high-quality product designed for grinding PCD/PCBN materials, offering precise and efficient performance for various applications. With a brand origin from CHINA and CE certification, this machine ensures reliability and quality in its operation.
The PCD Grinding Machine is versatile and can be used in a wide range of scenarios, making it suitable for different industries. Its minimum order quantity is 1, and it is packaged in a sturdy plywood box for secure transportation. The delivery time for this machine is 45-60 days, and payment terms accepted include TT, LC, and Western Union.
Equipped with a tip radius of 0-70mm, the CTSTC PCD Grinding Machine provides flexibility in grinding operations, allowing for precision and accuracy. The cross table swiveling angle of 270° enables easy adjustment and positioning for optimal results.
Users can make use of the grinding wheel height adjustment feature, with a range of 140mm, to cater to different workpiece sizes and requirements. Additionally, the grinding wheel oscillation distance is adjustable from 0-40mm, providing versatility in grinding applications.
With a spindle power of 2.2kw, this PCD grinder delivers robust performance for machining PCD/PCBN materials with ease. Whether in tool manufacturing, automotive, or aerospace industries, the CTSTC PCD Grinding Machine is a reliable choice for achieving precision and efficiency in grinding operations.
Customization:
Product Customization Services for the PCD Grinding Machine:
Brand Name:
CTSTC
Place of Origin:
CHINA
Certification:
CE
Minimum Order Quantity:
1
Packaging Details:
plywood box
Delivery Time:
45-60 days
Payment Terms:
TT/LC/Western Union
Optical Tube Distance:
300mm
Image Magnification:
45-250 Times (digital Zoom)
Net Weight:
1450kgs
Grinding Wheel Oscillation Distance:
0-40mm (adjustable)
Size of Cross Table:
210*160mm With 4T Grooves
Support and Services:
The PCD Grinding Machine product comes with comprehensive Product Technical Support and Services to ensure optimal performance and customer satisfaction. Our dedicated team of experts is available to provide technical assistance, troubleshooting guidance, and product maintenance support. Additionally, we offer training services to help users maximize the capabilities of the machine and achieve the best results.
